Introductions
This machine also supports plasma cutting function. The overall power conversion efficiency exceeds 85%, making it highly energy-saving.
Specifications
| Power Voltage | AC230V 50/60HZ |
| Input power capacitance (KVA) | 4.8 |
| Rated input current (A) | 22 |
| Rated output current (A) | 160 |
| Range of output current (A) | Tig:20-160,Cut:15-40 |
| No-load voltage (V) | 56 |
| Working voltage (V) | 18 |
| Pre-flow (S) | 0-2 |
| AC output frequency (Hz) | 60 |
| Clean width (%) | 20-80 |
| Slop-down time (S) | 0-5 |
| Tail-gas time (S) | 2-10 |
| Remote control | Yes |
| ARC-leading | HF vibration |
| Duty Cycle | 60% |
| Power factor | 0.93 |
| Max cutting thickness (MM) | 12 |
| Max welding thickness (MM) | 10 |
| Insulation class | B |
| Case Protection Level | IP21 |
| High Frequency Arc Striking | Yes |
| Weight（Kg) | 20 |
| Dimensions (MM) | 493 × 330 × 320 |
Package Includes
- Unit
- The tig leads 4.5m with torch
- Cutter leads 4.5m with torch
- Spare tips of torch and Ceramics
- Tungsten( diameter 1.6mm X 150mm)
- Arc leads 4m
- Earthed leads 3m
One-year back to base warranty (Auckland)
