160A Tig/Stick/40Amp Plasma cutter 3in1(CT-416)
Introductions
*CT-416 TIG/Stick/Cut 3-in-1 Welding Machine: Trendy Design with Enhanced Safety Performance
*The CT-416 is a multifunctional welding machine built with advanced inverter technology, combining three core functions: TIG welding, MMA stick welding and plasma cutting. It is widely applicable for welding and cutting carbon steel, stainless steel, alloy steel, copper and other non-ferrous metals. Featuring portability, high efficiency, low energy consumption and stable output, the machine boasts a duty cycle up to 85%.
*It can be used as a Tig with our special tig torch.
Specifications
| Power Voltage | AC230V 50/60HZ |
| Input power capacitance (KVA) | 3.8 |
| No-load loss (W) | 40 |
| Duty Cycle | 50% |
| Power factor | 0.93 |
| Efficiency | 85% |
| Insulation class | F |
| Case Protection Level | IP21 |
| Cut thickness (MM) | 1-12 |
| Weight (Kg) | 13.4 |
| Dimensions (MM) | 440 × 218 × 355 |
Package Includes
- Unit
- The tig leads 4m with torch and safety controller plug
- Cutter leads 4m with torch
- Tungsten( diameter 1.6mm)
- Arc leads 3m
- Earthed leads 3m
- Air flow regulator
- Argon regulator
One-year back to base warranty (Auckland)
