TIG-200P DC TIG/Stick with Pulse Welder (2-in-1)
Introductions
The TIG‑200P Inverter TIG Welder supports Pulse TIG and MMA Stick Welding, covering DC Stick and DC TIG welding modes.
This model cannot weld aluminum. If you need to work with aluminum and its alloys, please refer to our AC/DC welder listings.
It is suitable for welding carbon steel, alloy steel, iron, stainless steel, copper, titanium and their various alloys.
Widely applicable for machinery, chemical engineering, shipbuilding, automobile manufacturing, architectural decoration and other industries.
Specifications
| Power Voltage | AC 230V 50/60Hz |
| Rated Input Current (A) | 20 |
| Rated Input Capacity (KVA) | 4.8 |
| Rated Output Current (A) | 10 - 200 |
| No-load Voltage (V) | 42 |
| Rated Duty Cycle | 60% |
| Crest Current (A) | 8 - 200 |
| Base Current | 8 - 200A |
| Pulse Frequency (Hz) | 0.5 - 200 |
| Pulse Rate | 0.1 - 0.9 |
| Post Flow Time (S) | 1 - 10 |
| HF Arc Striking | Yes |
| Dimensions (MM) | 423 × 205 × 357 |
| Weight (Kg) | 9 |
Package Includes
- Unit
- SR-26 TIG torch with 4m leads
- Spare tips of torch and ceramics
- Tungsten (diameter 1.6mm)
- Arc leads 3m
- Earthed lead 3m
One-year back to base warranty (Auckland)
