Introductions
Ignition system: C.D.I Fuel:
Mixture ( Gasoline 25: Two cycle oil 1 ) Fuel tank
capacity: 550 (ml) Chain oil: Motor oil SAE#10W-30 Oil
tank capacity: 260 (ml ) Engine displacement: 58 ( cc)
Maxi engine power: 2.6kw / 7500rpm Maxi speed with
cutting attachment: 10000rpm Maxi engine speed at idling:
2800rpm Maxi cutting length: 50 (cm) Sprocket: 7T x
0.325 Saw chain type: Carlton/Oregon/Stihl Saw chain
pitch: 0.325/0.375(in) Saw chain gauge: 0.058/0.063(in)
Guide bar type: Sprocket nose Guide bar size: 22(inch)
Oil feeding system: Automatic pump with adjuster
Compression ratio:7.5:1 Net Weight(without guide bar
and chain): 7.2kg Gross weight(With 22in cutting
attachment):8.2Kg Dimensions: 530 x 280 x 300mm
Accessories included: - Bar cover - Fuel mixing
bottle - Tool kit - Instruction Manual
Three
month warranty back to base Auckland
----------------------------------------------------------------------------------------------------------------- |
